4840.00 rub.
Description
Designed for:
- receiving signals from third-party technical means of fire automation with a relay output and its further use in the system as a logical event. As such technical means can be, for example, third-party power supplies (with a relay output) or PPKP;
- transfer of relay control signals to third-party engineering, technological equipment and other devices involved in ensuring fire safety.
Features:
- 2 independent inputs and 2 independent outputs (optocouplers);
- control of the state of the primary circuit of optcouplers;
- the ability to configure logical events for inputs and outputs.
Technical Specifications:
Parameter |
Maximum value |
The voltage in the SLI is | 18 - 24 V |
Current consumption from the SLI, no more: in the "Closed optocoupler" mode in all other modes |
4, 2 mA 0,2 mA |
Maximum load on the optocoupler | 60V, 600 mA |
Enclosure degree of protection |
IP20 |
Dimensions, not more than |
98х90х34 mm |
Weight, not more than |
0,25 kg |
