vendor code 00-00012753
4951.00 rub.
Description
They are designed to receive signals from third-party technical means of fire automation with a relay output and further use it in the system as a logical event. As such technical means can be, for example, third-party power supplies (with relay outputs) or PPKP.
Features:
- Monitoring the state of the relay contacts:
MKV4-I - 4 independent inputs;
- Automatically monitors inputs for open and short circuits (by resistance);
- Ability to configure the logical events generated by triggering inputs;
- The length of the communication line is not more than 1m.
Technical Specifications:
|
Parameter |
Maximum value |
| Voltage in the SLI | 18 - 24 V |
|
Current consumption from the SLI, max |
0,2 mА |
|
Enclosure degree of protection |
IP20 |
|
Overall dimensions, not more than |
98х90х34 mm |
| Weight, not more than |
0,25 kg |
Characteristics
| Consumption current | 0,2 mА |
| Dimensions, mm | 93х104х34 mm |
| Power supply: current, no more | 0,2 mА |
| Power supply: voltage | from 19 to 27 В |
| Sheath protection degree | IP41 |
| Temperature regime | from -5 to 55 °C |
| Weight | 0,25 kg |
