Description
They are designed to receive signals from third-party technical means of fire automation with a relay output and further use it in the system as a logical event. As such technical means can be, for example, third-party power supplies (with relay outputs) or PPKP.
Features:
- Monitoring the state of the relay contacts:
MKV2-I - 2 independent inputs;
- Automatically monitors inputs for open and short circuits (by resistance);
- Ability to configure the logical events generated by triggering inputs;
- The length of the communication line is not more than 1m.
Technical Specifications:
Parameter |
Maximum value |
Voltage in the SLI | 18 - 24 V |
Current consumption from the SLI, max |
0,2 mА |
Enclosure degree of protection |
IP20 |
Overall dimensions, not more than |
90х40х40 mm |
Weight, not more than |
0,25 kg |
Characteristics
Consumption current | 0,2 mА |
Dimensions, mm | 113х41х38 mm |
Power supply: current, no more | 0,2 mА |
Power supply: voltage | from 19 to 27 В |
Sheath protection degree | IP41 |
Temperature regime | from -5 to 55 °C |
Weight | 0,25 kg |
